9 Fast Ethernet Ports with 8 PoE+ Ports: Features nine 10/100 Mbps RJ45 ports, with Ports 1-8 supporting the PoE+ standard (802.3at/af). This allows for flexible deployment of PoE-compatible devices such as IP cameras, wireless access points, and IP phones, delivering both power and data over a single Ethernet cable.
65 W PoE+ Power Budget: Offers a total PoE power budget of 65 W across the eight PoE+ ports. Each PoE+ port supports up to 30 W output, ensuring ample power for a wide range of standard and high-power PoE devices.
Up to 250 m PoE Transmission (Extend Mode): With the "Extend Mode" enabled (via a physical button), the PoE transmission distance can reach up to 250 meters (820 feet) for ports 1-8. This is particularly beneficial for surveillance camera deployments in larger or remote areas, significantly reducing cabling costs. Note: The speed of the ports in Extend Mode will downgrade to 10 Mbps.
Priority Mode for Critical Devices: A dedicated "Priority Mode" (via a physical button) ensures that high-priority ports (Port 1 and Port 2) receive power preferentially in scenarios where the total power consumption might exceed the budget. This guarantees stable operation for your most critical connected devices.
PoE Auto Recovery: Automatically detects and reboots unresponsive or dropped PoE-powered devices, enhancing system reliability and minimizing the need for manual intervention, especially crucial in surveillance applications.
Plug and Play: Offers hassle-free installation with no configuration required. Simply connect your Ethernet cables and the power adapter for instant network expansion and PoE power delivery.
Fanless Quiet Operation: The fanless design ensures silent operation, making it ideal for noise-sensitive environments such as homes, offices, and recording studios.
Durable Metal Casing: Features a robust and durable metal casing, providing enhanced protection for internal components and contributing to a longer product lifespan.
Desktop Design: Its compact design allows for flexible placement on a desktop.
Unmanaged Switch: A simple and straightforward unmanaged switch, requiring no complex setup, software, or ongoing management, making it user-friendly for basic network expansion and PoE power delivery.
Green Technology: Incorporates energy-efficient technology that intelligently adjusts power consumption based on the link status and cable length, helping to reduce energy consumption and operational costs.
IEEE 802.3x Flow Control: Supports IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode, which helps alleviate traffic congestion and ensures reliable data transfer.
Interface: 9 times 10/100 Mbps RJ45 Ports (8 times 10/100 Mbps 802.3at/af PoE+ Ports), AUTO Negotiation, AUTO MDI/MDIX
PoE Ports (RJ45):
Standard: 802.3at/af compliant
PoE Ports: Ports 1–8
Power Output per Port: Up to 30 W
PoE Power Budget: 65 W
Network Media:
10BASE-T: UTP category 3, 4, 5 cable (le 100m)
100BASE-TX: UTP category 5, 5e cable (le 100m)
Fan Quantity: Fanless
Installation: Desktop
External Power Supply: External Power Adapter (Output: 53.5VDC / 1.31A)
LED Indicators: Power, Link/Act, PoE Status, PoE MAX
Dimensions (W times D times H): 7.9 times 4.0 times 1.0 in (201 times 102 times 25 mm)
Max. Power Consumption:
2.73 W (no PD connected)
74.88 W (with 65 W PD connected)
Max. Heat Dissipation:
9.32 BTU/h (no PD connected)
255.49 BTU/h (with 65 W PD connected)
Switching Capacity: 1.8 Gbps
Packet Forwarding Rate: 1.339 Mpps
MAC Address Table: 2K
Jumbo Frame: 2 KB
Transfer Method: Store and Forward
Advanced Features: Extend Mode Button (Ports 1–8, up to 250 m PoE), Priority Mode Button (Ports 1–2), PoE Auto Recovery Button (Ports 1–8), Compatible With IEEE 802.3af/at Compliant PDs, Mac Address Auto-Learning and Auto-Aging, Green Technology.
Certifications: CE, FCC, RoHS
Environment:
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
