Type Flatbed Scanner Scanning element CIS Light source 3-color (RGB) LED Optical resolution 2400 x 4800dpi¹ Selectable resolution 25 - 19200dpi Interface Hi-Speed USB 2.0 Scanning gradation (colour) 48bit input -> 48/24 bit output Scanning gradation (greyscale...

Type
Flatbed Scanner
Scanning element
CIS
Light source
3-color (RGB) LED
Optical resolution
2400 x 4800dpi¹
Selectable resolution
25 - 19200dpi
Interface
Hi-Speed USB 2.0
Scanning gradation (colour)
48bit input -> 48/24 bit output
Scanning gradation (greyscale)
16 bit input -> 8 bit output
Maximum document size
A4 / Letter (216 x 297mm)
EZ-Scan Buttons
4 buttons (PDF, AUTOSCAN, COPY, SEND)
Scanning speed (colour)
3.7 msec/line (300 dpi), 16.7 msec/line (2400dpi)¹
Scanning speed (greyscale)
3.7 msec/line (300 dpi), 5.6 msec/line (2400dpi)¹
Scan speed (A4, 300dpi, Colour)
Approx. 16 sec¹
Software included
Scan Utility, Quick Menu, My Image Garden
Power supply
Supplied via USB port
Power consumption
approx. 2.5W (in operation, maximum)
approx. 1.5W (standby)
approx. 11mW (suspend)
Dimensions
250 x 370 x 40 mm
Weight
1.6kg
Operating range (temperature)
5 - 35 °C
Operating range (humidity)
10 - 90 %RH, without condensation formation
Supported Operat

GENERAL Max Supported Document Size 216 x 3100 mm ManufacturerHP POWER DEVICE Nominal Voltage AC 120/230 V Frequency Required 50/60 Hz Power Consumption Stand by 4.73 Watt Power Consumption Sleep 1.68 Watt Type external power adapter MEDIA HANDLING M...

GENERAL
Max Supported Document Size 216 x 3100 mm
ManufacturerHP
POWER DEVICE
Nominal Voltage AC 120/230 V
Frequency Required 50/60 Hz
Power Consumption Stand by 4.73 Watt
Power Consumption Sleep 1.68 Watt
Type external power adapter
MEDIA HANDLING
Max Document Size 8.5 in x 3100 mm
Supported Document Size Details ADF - up to 216 x 3100 mm
Flatbed - up to 8.5 in x 11.7 in
Feeder Capacity 50 sheets
Document Feeder Type Automatic
MISCELLANEOUS
Color Category black, white
ENVIRONMENTAL STANDARDS
ENERGY STAR Qualified Yes
SOFTWARE / SYSTEM REQUIREMENTS
Software Included Readiris Pro, Cardiris, ArcSoft PhotoStudio, Nuance PaperPort, HP Scan, HP Scanner Tools Utility
System Requirements Details Windows 7/8/8.1/10 - 2 GHz - RAM 2 GB - HD 170 MB
MacOS X 10.9/10.10 - RAM 1 GB
INTERFACES
Interface USB 2.0
Connector Type Type B
SCANNER
Optical Resolution 1200 dpi x 1200 dpi
Automatic Duplexing Yes
Type document scanner
Scanner Speed Details 20 ppm - 300 dpi
40 ipm -

Scanner type Sheetfed Scan resolution, optical Up to 600 dpi (colour and monochrome, sheet-feed) Duty cycle (daily) Recommended for 3,500 pages per day Bit depth 24-bits external/48-bits internal Levels of grayscale 256 Task speed 10 x 15 cm colour ...

Scanner type
Sheetfed
Scan resolution, optical
Up to 600 dpi (colour and monochrome, sheet-feed)
Duty cycle (daily)
Recommended for 3,500 pages per day
Bit depth
24-bits external/48-bits internal
Levels of grayscale
256
Task speed
10 x 15 cm colour photo to file (200 dpi, 24-bit, tiff): about 6.27 sec for single image scan
OCR A4 (200dpi, 24-bit to RTF): about 7.45 sec for single image scan
10 x 15 cm colour photo to email (150 dpi, 24-bit): about 5.95 sec for single image scan, about 1.08 sec for single image send to email, totally 7.03 sec
A4 PDF to email (300 dpi, 24-bit): about 7.36 sec for single image scan, about 1.7 sec for single image send to email, totally 9.06 sec
Media types
Cut sheet paper, printed paper (laser and ink), pre-punched paper, bank checks, business cards, freight bills, carbonless forms, previously stapled media with staple removed
Media weights, supported ADF
40 to 413 g/m²
Scan file format
For text and images: PDF, JPEG, PNG, BMP, TIFF, T
